Double Gates with Aluminium Frame | Arched Top | W: 2.8m - 3.6m, H: 1800mm

2 x Aliminum Posts + Post Caps

2 x PVC Gate Leafs With 3" x 1" Ali Frames Fitted

Hinges, Latches, Key Locks, Drop Bolts & Pad Bolts are all optional extras, due to the amount of variations for this type of Gate. Please see our fixings page.

Measuring Your Gate Opening: To ensure an accurate fit, we need to know the total gap, including the posts. Here’s how to measure.

Measure the Total Gap: Measure the distance from wall to wall, or from wall to fence. Be sure to measure at the top, middle, and bottom of the opening to account for any variations.

Provide the Smallest Measurement: After measuring, record the smallest measurement from top, middle, and bottom in the "Total Gap" box. This will ensure a precise fit for your gate.

Post Thickness and Clearance: Once we receive the smallest measurement, we will subtract the thickness of the posts and include the appropriate clearance for a proper fit.

If you're unsure about the measurements or need assistance, please don’t hesitate to contact us, and we’ll guide you through the process.

Existing Posts: If you plan to keep your existing posts, or one of them, let us know. Our standard gate package includes two posts, unless you specifically request otherwise.

We have two main areas that we fit from, using our own team of Tekplas gate fitters

Our Local Areas are below: Camberley & Southend

All Garden/Driveway Gates: Fuel & Travel Local Area = Free = Up to 10miles

Fuel & Travel Outside Of Our Local Area 10-40 Miles £30.00

Fuel & Travel Outside Of Our Local Area 40 –60 Miles £50.00

Double Gate Install £210.00 = No Existing Gate To Remove

Single Gate Install £210.00 & Remove Existing Gate And Dispose of £40.00 Extra

Traveling into London due to the charges, will cost slightly more.

Cementing posts into the ground £60 Per Post Inc 2 x Bags Of Post Mix

We will come out and measure up for you if your not happy measuring yourself within a certain area. Please contact us
for pricing.

Standard Gate Height: 1800mm Start Of Arch Rising To Roughly 1950mm

Post Height 1830mm or 2250-2400mm If cemented into the ground.

Rebate Strip: For double gates, we include a rebate strip on one gate. This allows one gate to remain stationary, while the other opens as needed. Please specify whether you would like the rebate strip installed on the left or right gate (as viewed from the front). If you prefer both gates to open forward, this can be arranged.

Please leave the Left Side or Right Side in the customer notes or by selecting on the options.

All of our gates come with an instruction pack and
we also have videos on Youtube.

The accuracy of the dimensions specified by you
will reflect the fit quality.

We recommend a professional or skilled handy
person installs them.

Stainless Steel Hardware is advised for gates
fitted near the sea or in corrosive areas.

Please call Customer Services should you
experience any difficulties during the installation.

We do not advise fitting 3rd party locks or latches and cannot be held responsible if they cause fitting issues.

Gate Care & Maintenance Guide: To keep your Tekplas gate looking fresh and working correctly, we recommend performing simple maintenance twice a year—once at the start of spring and again at the end of summer.

Step 1: General Cleaning

• Hose down the gate to remove surface dirt and grit.
• Wash thoroughly with hot soapy water and a soft sponge. This helps remove any build-up from winter weather or heavy rainfall.

Step 2: PVC Surface Treatment

• Once dry, use a PVC solvent cleaner to restore the finish. We highly recommend Everbuild PVC Solvent Cleaner, which we've tested extensively for the best results.
• Spray directly onto the gate and wipe with a clean cloth. This step helps maintain the gate’s appearance, especially for coloured gates, by protecting against fading from UV exposure.

Step 3: Optional UV Protection (for Gates in Full
Sun)

• If your gate is exposed to strong sunlight all year round, apply a clear Danish Oil with a UV additive.
• Only use clear Danish Oil designed for external use with UV protection.
• Apply with a cloth to help prolong the vibrancy of your gate’s colour.

Note: While Tekplas gates are made from the highest-grade PVC with up-to-date UV stabilisers, all PVC materials can eventually after many many years show signs of fading with prolonged full sun exposure. These care steps help extend the life and appearance of your gate.

Step 4: Hardware Maintenance

• Use a light machine oil on a cloth to wipe down all hardware including:
• Hinges
• Ring latches
• Locks
• Add a few drops directly to hinge joints to keep them operating smoothly and to protect against rust and wear.

Why Maintain Your PVC Gate?

Unlike timber, PVC won’t rot, absorb water, or dry out and split during the summer months. It also won’t need repainting like traditional wooden gates, saving you time and ongoing maintenance costs. With just a small amount of care, your Tekplas gate will continue to look great and function smoothly for many years to come.
